5/3-way (center closed) pneumatic solenoid valve with G1/4 inch ports (female thread), G 1/8 inch exhaust ports and 220 V AC coil. Indirect operated (internally piloted). Applications include controlling double-acting cylinders with intermediate positions. Operating pressure from 0.15 to 0.8 mpa(21to 114 psi). Only suitable for air. With manual override control. Can be mounted on manifold with central air supply/vent. Response time 0.05 s, temperature range of -5 to 60°C.

Cons

• Only for (clean) air, not for other media or vacuum

• Minimal pressure of 3 bar required for proper operation (pilot operated valve)

Specification

Connection size: 1/4 1/2 inch

Voltage: 220 V AC 24VDC

Material: Aluminium

Seal material: HNBR

Function: Center closed

Valve ports/positions: 5/3 way 3/2 way

Operation: Indirect

Connection type: Inner thread cylindrical BSPP-G
